產品名稱:
規格型號 | 寬度/W | 厚度/T | 每卷米數/M | 每米重量/Kg | 使用搭扣 | 配套工具 | |||
mm | Inch | mm | Inch | Length/m | Weight/m | ||||
SS-0.25*6.35 | 6.35 | 1/4 (0.25) | 0.25 | 0.01 | 50/100 | 0.0127 | L型扣 STT萬能型扣 STL旋轉型扣 | J020 CT04 C001 LQA | |
SS-0.25*7.9 | 7.9 | 5/16 (0.31) | 0.0158 | ||||||
SS-0.25*10 | 10 | 3/8 (0.39) | 0.02 | ||||||
SS-0.25*12 | 12 | 1/2 (0.5) | 0.024 | ||||||
SS-0.3*6.35 | 6.35 | 1/4 (0.25) | 0.3 | 0.012 | 50/100 | 0.0152 | L型扣 STT萬能型扣 STL旋轉型扣 | J020 CT04 C001 LQA | |
SS-0.3*7.9 | 7.9 | 5/16 (0.31) | 0.0189 | ||||||
SS-0.3*10 | 10 | 3/8 (0.39) | 0.024 | ||||||
SS-0.3*12 | 12 | 1/2 (0.5) | 0.0288 | ||||||
SS-0.3*16 | 16 | 5/8 (0.63) | 0.0384 | ||||||
SS-0.3*19 | 19 | 3/4 (0.75) | 0.0456 | ||||||
SS-0.4*6.35 | 6.35 | 1/4 (0.25) | 0.4 | 0.016 | 30/50 | 0.0203 | L型扣 LS螺絲型扣 STT萬能型扣 STL旋轉型扣 | J020 CT04 C001 LQA | |
SS-0.4*10 | 10 | 3/8 (0.39) | 0.0323 | ||||||
SS-0.4*12 | 12 | 1/2 (0.5) | 0.0384 | ||||||
SS-0.4*16 | 16 | 5/8 (0.63) | 0.0512 | ||||||
SS-0.4*19 | 19 | 3/4 (0.75) | 0.0608 | ||||||
SS-0.5*6.35 | 6.35 | 1/4 (0.25) | 0.5 | 0.02 | 30/50 | 0.025 | L型扣 LS螺絲型扣 | LQA C001 | |
SS-0.5*9.5 | 10 | 3/8 (0.39) | 0.0361 | ||||||
SS-0.5*12.7 | 12.7 | 1/2 (0.5) | 0.05 | ||||||
SS-0.5*16 | 16 | 5/8 (0.63) | 0.064 | ||||||
SS-0.5*19 | 19 | 3/4 (0.75) | 0.076 | ||||||
SS-0.6*6.35 | 6.35 | 1/4 (0.25) | 0.6 | 0.024 | 30/50 | 0.03 | L型扣 LS螺絲型扣 | LQA C001 | |
SS-0.6*9.5 | 10 | 3/8 (0.39) | 0.048 | ||||||
SS-0.6*12.7 | 12.7 | 1/2 (0.5) | 0.06 | ||||||
SS-0.6*16 | 16 | 5/8 (0.63) | 0.077 | ||||||
SS-0.6*19 | 19 | 3/4 (0.75) | 0.091 | ||||||
SS-0.7*9.5 | 10 | 3/8 (0.39) | 0.7 | 0.027 | 30/50 | 0.056 | CX牙型扣 LS螺絲型扣 | LQA C001 | |
SS-0.7*12.7 | 12.7 | 1/2 (0.5) | 0.071 | ||||||
SS-0.7*16 | 16 | 5/8 (0.63) | 0.089 | ||||||
SS-0.7*19 | 19 | 3/4 (0.75) | 0.106 | ||||||
SS-0.76*9.5 | 10 | 3/8 (0.39) | 0.76 | 0.03 | 30 | 0.06 | CX牙型扣 | LQA C001 | |
SS-0.76*12.7 | 12.7 | 1/2 (0.5) | 0.0722 | ||||||
SS-0.76*16 | 16 | 5/8 (0.63) | 0.0972 | ||||||
SS-0.76*19 | 19 | 3/4 (0.75) | 0.1155 | ||||||
SS-1.0*12.7 | 12.7 | 1/2 (0.5) | 1.0 | 0.039 | 30 | 0.1016 | CX牙型扣 | G402 | |
SS-1.0*16 | 16 | 5/8 (0.63) | 0.128 | ||||||
SS=1.0*19 | 19 | 3/4 (0.75) | 0.152 | ||||||
SS-1.0*25 | 25 | 1 (0.98) | 0.2 | ||||||
SS-1.0*32 | 32 | 1－1/4 (1.26) | 0.256 | ||||||
SS-1.1*19 | 19 | 3/4 (0.75) | 1.1 | 0.043 | 30 | 0.167 | CX牙型扣 | G402 | |
SS-1.1*25 | 25 | 1 (0.98) | 0.22 | ||||||
SS-1.1*32 | 32 | 1－1/4 (1.26) | 0.281 | ||||||
